4800

4800
Specification Value
Truss Size 48 in / 1.2 m
Max Paving Width 116 ft / 35.3 m
Operating Weight (Standard) 10,473 lbs / 4,750.5 kg
Truss Depth 48 in / 1.2 m
Machine Length ■ 36 ft / 11.0 m standard, can be extended to 120 ft / 36.6 m
■ Capable of larger spans with factory consultation
Paving Width ■ Standard: 32.5 ft / 9.9m
■ Minimum: 12 ft / 3.6 m
■ Maximum: 116 ft / 35 m
Legs Heavy duty 6 in / .015 m diameter
Machine Travel 4 ft (1.2 m) wheelbase (two drivers, two idlers bogies)
Crown Manual
Operating Weight 10,473 lbs / 4,750.5 kg
Paving Carriage ■ Dual 5 ft / 1.5 m long paving rollers
■ Dual adjustable strike-off augers with double flighting meter
■ Patented 11.5 in / .29 m Rota-Vibe®
■ Paving roller direction control valves
■ Paving carriage pivot cylinder
■ Automatic roller rotation kit
■ Adjustable finishing pans with burlap drag or astro-grass
■ Turntable mounting to allow for skewed decks without a crown
■ Eight (8) bogied carriage rollers with hold-down rollers and side
trust rollers
■ Dual-chain carriage drive
Power Two interchangeable 23 HP / 17.1 kW gas engines with 12-volt electric starters, one mounted on the frame at the operator's station that drives the machine and carriage travel.
The second is mounted on the carriage and drives the paving rollers and two augers.
Automatic Operation ■ Total automatic machine operation
■ Automatic machine move-up at the end of each paving carriage
pass 0-15 in / .38 m
■ Automatic cushioned paving carriage travel reversal
■ Operator can stop and reverse carriage travel at any point
