The Colt 600 Compact Scalping Screen has been specifically designed for operators for whom versatility, maneuverability and transportability are of key importance. It is small enough to fit inside a container for transport but strong enough to withstand the toughest of applications. The Colt 600 is a compact and aggressive forward facing screen that can work in aggregates, sand and gravel, top soil, construction demolition and recycling applications where site space is at a premium. With the large range of screen media available including bofor bars, finger screens, woven mesh and punch plates it provides the user with a level of versatility that is second to none.
Specification Value Transport Length 36' 10.98m Transport Width 7' 5" 2.25m Transport Height 8' 4" 2.55m Double Deck Screen 8' x 4' 2.34m x 1.17m Output Potential 308 US tph 280tph
The Colt 800 Mobile Screening Machine is a compact and aggressive forward facing incline screen. This versatile plant can work in aggregates, sand and gravel, top soil, construction demolition and recycling applications where site space is at a premium. The highly aggressive screenbox can accept a range of media including bofor bars, finger screens, woven mesh and punch plates. Its compact size, quick set-up times, ease of transport and ease of operation makes the Colt 800 the ideal solution for all small to medium sized operators.
Specification Value Transport Length 30' 3" 9.22m Transport Width 8' 2" 2.5m Transport Height 10' 1" 3.09m Double Deck Screen 9' x 4' 2.77m x 1.22m Output Potential 308 US tph 280tph
The highly adaptable Colt 1000 Scalping screen is able to operate in both heavy duty scalping and precision screening applications and will manage the most difficult of materials. The Colt 1000 achieves a compact footprint maintaining the ethos of the EvoQuip range while achieving versatility and mobility. Flexibility is enhanced with configurable conveyor options and two way split conversion. Featuring an aggressive double deck screen, variable screening angle with numerous screen media options, broad fines conveyor, quick set up time and tall discharge heights ensures the Colt 1000 distinguishes itself amongst its competition.
Specification Value Transport Length 35' 11" 11m Transport Width 8' 2" 2.5m Transport Height 10' 4" 3.1m Double Deck Screen 13'6'' x 4' 4.1m x 1.22m Output Potential 396 US tph 360tph
The high capacity, versatile heavy duty Colt 1600 Screen is designed to work in primary and secondary screening applications. With the single, triple shaft and Spaleck screen box options the applications are endless. The Colt 1600 is available with dual power technology giving flexibility to be powered by an external power supply or the standard on-board engine.
Specification Value Transport Length 49' 1" 14.95m Transport Width 9' 11" 3.0m Transport Height 11' 2" 3.36m Double Deck Screen 16' x 5' 4.8m x 1.53m Output Potential 600 US tph 600tph
