I-120 Electric

The Finlay® I-120 electric impact crusher has been designed to meet the needs of customers for whom electricity is the preferred power source. The intelligent and flexible design of the power pack enables the machine to be connected directly to the grid or a genset electrical power source.

In operational mode the plant’s electrical drive system powers the feeder, crusher and all conveyors without compromising on performance and flexibility in applications.

For ease of transport the machine is fitted with an onboard engine that can be engaged for powering the tracks to enable movement around the job site. As the world moves towards a more environmentally friendly future investing in electric powered equipment can position your business to a long-term sustainability and compliance with changing regulations.

Key Features:

  • Significant reduction in operating costs by powering from grid electricity.
  • Reduced carbon footprint with the elimination of Co2 gas emissions and reduction in engine noise when operating in both urban and indoor environments.
  • Electric powered equipment typically require less maintenance than diesel counterparts reducing maintenance costs.
  • Maximised machine availability and uptime as scheduled service interval periods are longer.
  • Electric crushers are generally more energy-efficient and cost effective to operate compared to diesel powered crushers.

Technical Documentation

Power

Net Engine Power: Tier 4 Final Scania DC9 400 hp Scania DC9 294 kW
Net Engine Power: Tier 3 / Stage IIIA CAT C9.B 335 hp CAT C9.B 250 kW
Net Engine Power: Stage V Scania DC9 400 hp Scania DC9 294 kW

Measurements

Weight 88,074 lbs incl. Options 39,950 kg incl. Options
Rotor Size Ø41”x 44” Ø1033x1100mm

Productivity

Output Potential 441 US tph 400 tph
