Track Trommels
Static Trommels
Recycling Trommels
Conveyors
Scalping Grids
We are widely known for our heavy-duty track trommel screens and there is a range of models available in our track trommel product range that cater for the diverse customer needs. The designs are revolutionary and innovative with several added features which have allowed us to increase working life and productivity. Our units are primarily used in applications like recovering rocks from overburden, cleaning off sticky clay from rocks, riprap/armour rocks, processing blasted rocks up to 32” (800mm) in size, recycling and processing construction and demolition waste (C+D).
Scrap Pro 400 Rotary Screener
Untitled design (46)
Scrap Pro 400 Rotary Screener
Untitled design (46)

Scrap Pro 400

Scrap Pro 400 Rotary Screener
Untitled design (46)
Images
Scrap Pro 400 Rotary Screener
Untitled design (46)

Scrap Pro 400


The MDS Scrap Pro 400 track rotary screener is designed specifically for the scrap and metal recycling industry, offering a solution to long-standing challenges in processing efficiently. With its robust construction and advanced features, this machine is built to handle tasks that have traditionally been difficult for conventional equipment.

The Scrap Pro 400 is tailored for heavy-duty scrap processing, addressing a key gap in the market where standard recycling trommels and scalpers often fall short. It is equipped with a wear-resistant push feeder, capable of withstanding the abrasive nature of scrap materials, and a durable drum frame that supports a variety of screen sizes, ranging from 25mm to 150mm (1” to 6”). Additionally, it features an apron-style conveyor for handling oversized material and a heavy-duty three-ply fines belt, ensuring long-lasting performance in demanding environments.

With auto-reverse functionality and adjustable drum rotation speeds, the Scrap Pro 400 is designed for maximum efficiency and reliability, making it the ideal solution for businesses in the scrap and metal recycling industry seeking a machine that can handle the toughest materials with ease. Say goodbye to clogged decks, ripped belts and weak drums, say hello to your next solution.


Parts
Find A Dealer
Videos
OVERSIZE CONVEYOR
Discharge Height: 3100mm (10’2”)
Heavy Duty Apron style conveyor Single Heavy Duty
Motor Gearbox Drive
1000mm width (3’3”)

TRACKS
All terrain heavy duty tracks
Shoe Width 500mm (1’7”)
Length Centres 2.8m (9’2”)
Gauge Centres 2.19m (6’10”)
ENGINE
55kW (74HP)
CAT 2.2 Stage 5 Diesel Engine
Hydraulic Power Unit
Electronic Control System
Sensors for Blockage Prevention and Machine Monitoring
FINES CONVEYOR
1000m Width (3’3”)
Discharge Height: 3550mm (11’8”)
Single Hydraulic Drive
Heavy Duty Belt
HOPPER
4 Cubic Metre Capacity (5.23yd3)
Hydraulic Variable Speed Drive
Speed of 1-8 Strokes Per Minute
Wide Mouth Opening:
3.5m x 2.1m (11’6” x 6’11”)
PUSH FEEDER
Hydraulic Push Feeder
1m x 3.15m (3’4” x 10’4”)
Variable Speed Drive Heavy Duty
HEAVY DUTY DRUM
Welded Drum or Changeable Screens
4m (13’1”) long
1.25m (4’1”) Internal Diameter

Technical Documentation

Power

Engine CAT 2.2 74HP TIER 5 Diesel CAT 2.2 55kW TIER 5 Diesel

Productivity

Output Potential Up to 330 US tons per hour Up to 300 tonnes per hour

Measurements

Working Dimensions Length 61'2” | Width 8’ 2” | Height 9’ 10” Length 18637mm | Width 2500mm | Height 3009mm
Transport Dimensions Length 56’ 8” | Width 8’ 2” | Height 8'9" Length 17275mm | Width 2500mm | Height 2664mm
Weight 45193 lbs 21500 kg

Downloads

Others

.pdf Scrap_Pro_400_Technical Specification_Web_3d3be53e-36ce-4296-b35c-53d5f42a5d67
Scrap_Pro_400_Technical Specification
