Measurements
| Machine Length | 30 ft / 9.14 m |
| Weight | 11,000 lbs / 4,990 kg |
| Paving Width | Maximum recommended 84 ft / 25.6 m |
| Machine Travel | 4 ft / 1.2 m wheel base (four driver bogies) |
| 2 Paving Carriages (full canal paver) 1 paving Carriage (half slope paver) 1 paving Carriage (side slope) |
■ Dual 6 ft / 1.82 m long direct-drive paving roller ■ Dual adjustable, heavy-duty doube fligth direct-drive strike-off augers ■ Patented Rota-Vibe® ■ Slope paving drag pan system |
| Power | Two 35 HP / 26.2 kW liquid-cooled diesel engines with 12-volt electric starters, one mounted on the frame at the operator's console that powers the machine and paving carriage travel. The second is mounted on the carriage and powers the augers, paving rollers and Rota-Vibe®. |
| Automatic Machine Operation | Includes machine operation and all paving functions |
