D3 Module
Apron Feeder Module
Designed around our proven, high-performance Terex® Jaques D3 Apron Feeder, the D3 Apron Feeder Module offers a 200 - 450 TPH capacity. It features a three-piece hopper design made from thick 15mm (5/8”) wear resistant steel plate with mild steel reinforcing ribs. Options include an electrical power panel for feeder and discharge conveyor control and a variable speed controller for accurate speed control.
Specification | Value |
---|---|
Motor Size | 20 hp / 15 kW |
Working Dimensions | 24' 3" x 17' 6" x 15' 10" (LxWxH) / 7390 mm x 5340 mm x 4830 mm (LxWxH) |
Hopper / Feeder | 19.17 cubic yards / 14.66 cubic m |
