Telson Telescopic Conveyor Range

The Telson Telescopic Conveyor range features five specifications that are capable of 270° of radial movement and up to 19.5° working angle.

ProStack’s ability to tailor our telescopic conveyors to suit any job is what sets us apart. Mobility, Conveyor Belt, Radio Remote Control and many other options including Roller and Pulley Lagging and Dust Containment systems are all available. With a multitude of tried and tested options available you can be sure your demands will be met.

  • Rotating Telescopic Conveyor Telson 4-42

    Telson 4-42

    The Telson 4-42 Telescopic Conveyor has a working length of 42 metres and can be tailored to meet our customer's needs. Capable of 270° of radial movement and a max working angle of 18°.

    Specification Value
    Conveyor Length 137' 9" 42m
    Belt Width 36" 900mm
    Capacity 115,100 ton 100,000 Tonnes
    Stockpile Height 45' 11" 14,000 mm
    Stockpile Capacity 85,340 CU.YD 62,500 m3
    Learn more
  • Telson 10-52 Radial Telescopic Conveyor Thumbnail

    Telson 10-52

    The Telson 10-52 Telescopic Conveyor has a working length of 52 metres and can be tailored to meet our customer's needs. Capable of 270° of radial movement and a max working angle of 19.5°.

    Specification Value
    Conveyor Length 170' 7" 52m
    Belt Width 36" 900mm
    Capacity 200,814 ton 182,176 Tonnes
    Stockpile Height 57' 17,375 mm
    Stockpile Capacity 148,751 CU.YD 113,729 m3
    Learn more
  • Telson 10-58 Portable Telescopic Conveyor Thumbnail

    Telson 10-58

    The Telson 10-58 Telescopic Conveyor has a working length of 58 metres and can be tailored to meet our customer's needs. A transport length of 34.13 metres makes this a highly portable conveyor.

    Specification Value
    Conveyor Length 190' 3" 58m
    Belt Width 36" 900mm
    Capacity 262,287 ton 237,943 Tonnes
    Stockpile Height 59’ 4” 18,085 mm
    Stockpile Capacity 194,287 CU.YD 148,543 m3
    Learn more
  • Telson 15-52 Telescopic Stockpiling Conveyor Thumbnail

    Telson 15-52

    The Telson 15-52 telescopic conveyor has a working length of 52 metres and can be tailored to meet our customer's needs. A transport length of 34.2 metres makes this a highly portable conveyor.

    Specification Value
    Conveyor Length 168' 11.5" 51.5m
    Belt Width 42' 1050mm
    Capacity 200,814 ton 182,176 Tonnes
    Stockpile Height 57' 17,375 mm
    Stockpile Capacity 148,751 CU.YD 113,729 m3
    Learn more
  • Telson 15-58 Mobile Conveyor Thumbnail

    Telson 15-58

    The Telson 15-58 offers the highest stockpile capacity of ProStack's Telescopic Conveyors. It has a working length of 57.8 metres and can be tailored to meet any customer's needs.

    Specification Value
    Conveyor Length 189' 9" 57.8m
    Belt Width 42' 1050mm
    Capacity 262,287 ton 237,943 Tonnes
    Stockpile Height 59’ 4” 18,085 mm
    Stockpile Capacity 194,287 CU.YD 148,543 m3
    Learn more
