The ProStack Ranger series is made up of tracked conveyors in both high level and low level specifications. Heavy duty tracks as standard make these conveyors highly portable and versatile enough for many different applications. Each machine is easily transported while select models feature rotating undercarriages.
A wide variety of options are available so that each track mounted conveyor can be tailored to individual customers needs.
-
Ranger 24-RS
Prostacks Ranger 24-RS Wheeled Radial Conveyor is designed to be one of the most cost efficient and effective ways of stockpiling material on the market. Available in either Pit or Road towable variants, the Ranger 24-RS can meet the requirements of almost all applications.
Specification Value Conveyor Length 74' 10" 22.85m Belt Width 36" 0.9m Max Discharge Height 30' 1" 9.2m Max Capacity 330 US TPH 300 TPH -
Ranger 4-15L
ProStack's Ranger 4-15L Low Level Tracked Conveyor has a high level of portability and is suited to almost any working environment.
Specification Value Conveyor Length 51'2" 15.6m Belt Width 42" 1050mm Max Discharge Height 24'2" 7.37m Transport Weight 29,189lbs 13,240kgs Max Capacity 496 US TPH 450 TPH -
Ranger 4-15H
ProStack's Ranger 4-15H High Level Tracked Conveyor has a high level of portability and is suited to almost any working environment.
Specification Value Conveyor Length 51'2" 15.6m Belt Width 42" 1050mm Max Discharge Height 23'8" 7.2m Transport Weight 27,557lbs 15,500kgs Max Capacity 496 US TPH 450 TPH -
Ranger 5-21T
ProStack's Ranger 5-21T Tracked Conveyor is designed to work alongside the entire range of Terex crushing and screening equipment.
Specification Value Conveyor Length 62'6" 19.06m Belt Width 42" 1050mm Max Discharge Height 31' 9.45m Transport Weight 30,467lbs 13,820kgs Max Capacity 551 US TPH 500 TPH -
Ranger 5-24T
The ProStack Ranger 5-24T tracked mounted conveyor is suited to aggregate and quarrying applications.
Specification Value Conveyor Length 70'3" 21.4m Belt Width 42" 1050mm Max Discharge Height 34'1" 10.41m Transport Weight 36,927lbs 16,750kgs Max Capacity 551 US TPH 500 TPH -
Ranger 6-24H
The Ranger 6-24H is a high level tracked mounted conveyor with a belt length of 22.5 metres and a belt width of 1.2 metres.
Specification Value Conveyor Length 73' 10" 22.5m Belt Width 48" 1.2m Max Discharge Height 34' 4" 10.5m Max Capacity 661 US TPH 600 TPH -
Ranger 6-24L
The ProStack Ranger 6-24L is a low level tracked stockpiling conveyor with a belt length of 22.5 metres and a belt width of 1.2 metres.
Specification Value Conveyor Length 73' 10" 22.5m Belt Width 48" 1.2m Max Discharge Height 33' 1" 10.1m Max Capacity 661 US TPH 600 TPH -
Ranger 6-24LS
The ProStack Ranger 6-24LS is a Low Level Radial Tracked Conveyor with a rotating undercarriage, a belt length of 22.5 metres and a belt width of 1.2 metres.
Specification Value Conveyor Length 73' 10" 22.5m Belt Width 48" 1.2m Max Discharge Height 35' 8" 10.9m Max Capacity 661 US TPH 600 TPH -
Ranger 6-24HS
The ProStack Ranger 6-24HS is a High Level Rotating Tracked Conveyor with a belt length of 22.5 metres and a belt width of 1.2 metres along with a rotating carriage.
Specification Value Conveyor Length 73' 10" 22.5m Belt Width 48" 1.2m Max Discharge Height 35' 8" 10.9m Max Capacity 661 US TPH 600 TPH -
Ranger 6-24HSO
The ProStack Ranger 6-24SHO is a High Level Rotating Tracked Conveyor with a belt length of 22.6 metres and a belt width of 1.2 metres.
Specification Value Conveyor Length 74' 2" 22.6m Belt Width 48" 1.2m Max Discharge Height 32' 2" 9.8m Max Capacity 661 US TPH 600 TPH -
Ranger 6-24TR
The ProStack Ranger 6-24TR Tracked Radial Stockpiling Conveyor is the ideal solution for stockpiling after mobile crushing and screening plants.
Specification Value Conveyor Length 74'4" 22.7m Belt Width 42" 1050mm Max Discharge Height 34'9" 10.9m Transport Weight 43,651lbs 19,800kg Max Capacity 661 US TPH 600 TPH -
Ranger 6-31T
The ProStack Ranger 6-31T Tracked Conveyor stockpiler's extra length conveyor and increased power, allows for maximum mobility and flexibility, reducing or eliminating the use of wheeled loaders on site.
Specification Value Conveyor Length 92'7" 28.22m Belt Width 42" 1050mm Max Discharge Height 43'11" 13.1m Transport Weight 48,060lbs 21,800kg Max Capacity 661 US TPH 600 TPH
