3600 RC

3600
The new remote control system (Patent Pending) on the 3600 RC Bridge Deck Finisher continues to provide safe operation of the machine while adding convenience and enhanced communication between the operator, team members and the concrete placer. Even though the RC unit controls machine: engine, power legs, machine and carriage travel speed functions and can also control most accessories including power crown adjuster, power crown positioning screw and a standard universal carriage/drag pan fogging (excluding internal concrete vibration), the operator’s console is still functional as needed.
Specification Value
Truss Depth 36 in / 92 m
Max Paving Width 86 ft / 26.2 m
Operating Weight (Standard) 7,760 lbs / 3,519.9 kg

Truss Depth

36 in / 0.91 m

Machine Length

36ft / 11.0 m standard, can be extended to 90 ft / 27.4 m

Paving Width

■ Standard: 33 ft / 10.1 m
■ Minimum: 9 ft / 2.7 m
■ Maximum: 87 ft / 26.5 m

Legs

Heavy duty 6 in / 0.15 m diameter

Machine Travel

3 ft / 0.9 m wheel base (two driver and two idler bogies)

Crown Adjuster

Universal Power Crown

Standard Operating Weight

8,200 lbs / 3,720 kg

Paving Carriage

■ Dual8”strike-off augers with double flighting, meters concrete with
each pass
■ Patented Rota-Vibe®
■ Dual 4 ft / 1.2 m long paving rollers
■ Paving roller rotation kit
■ Adjustable finishing pan with burlap drag
■ Paving carriage pivot cylinder

Power

Standard: Two Kohler PRO EFI 25 HP / 18.6 kW air-cooled gas engines

Automatic Operation

■ Automatic machine move-up at the end of each paving carriage
pass 0-12 in / 0.37 m
■ Automatic cushioned paving carriage travel reversal
■ Operator can stop and reverse carriage travel at any point
