694+
The Finlay® 694+ portable triple deck screener has been developed to fulfil the demands of high production producers in quarrying, mining, sand and gravel, coal, woodchip and topsoil applications. The new high ...
693+ Spaleck
Inclined Screen
The Finlay® 693+ Spaleck is the ultimate in mobile fine screening and separation technology. At the heart of the plant is an innovative 2-deck German designed and constructed high performance aggressive screenbox with state of the art flip flow technology on both the top and bottom decks.
Its processing capabilities and application flexibility make the machine the ultimate tracked mobile solution for the processing and separation of recycling materials such as incineration slag, shredder light and heavy fraction, scrap metal, electronic scrap, compost, clay, quarry dust, agg-lime, plastic fractions, biomass, topsoil, ore and aggregates etc.
The model is available with hybrid technology consisting of on-board electrical motors permitting the flexibility to run the plant from an outside power supply or standard on-board engine
Key Features:
- Highly flexible and adaptable and capable of operating with ease in wet, moist, sticky, dry, mixed recycling, virgin ore and aggregate materials.
- Dynamic wear resistant screening mats ensure an efficient material flow.
- High acceleration forces of the screening mats ensures accurate screening and creates a self-cleaning effect preventing blinding of the screening mats.
- The Flip-Flow screen with boltless mounted screen mats avoids unnecessary cleaning and reduces maintenance times.
Downloads
Hopper / feeder
Main Conveyor
Screenbox
Fines conveyor
Oversize / midgrade conveyors
T-Link Telematics
Oversize / midgrade conveyors
Video Gallery
Terex Finlay 693+ Spaleck inclined screen
Terex Finlay 693+ Inclined Screen with Spaleck screenbox
Image Gallery
| Specification | Value |
|---|---|
| Net Engine Power: Tier 3 / Stage IIIA | Tier 3 - Cat 121hp | Tier 4F / Stage IV - Cat 110hp / Tier 3 - CAT 90kW | Tier 4F/ Stage IV - Cat 82kW |
| Screen | 20' x 5' / 5.8m x 1.5m |
| Weight | 76,831lbs / 34,850kg |
| Transport Dimensions | Height 11' 9'' | Width 9' 10'' | Length 63' 6'' / Height 3.58m | Width 3m | Length 19.36m |
| Working Dimensions | Height 23' 1'' | Width 58' 8'' | Length 64' 3'' / Height 7m | Width 17.9m | Length 19.6m |
REMOTE PLANT MAXIMISATION.
That's what Terex Finlays’ T-Link telematics system is all about.
T-Link telematics system is the optimum tool to connect you remotely to your Terex Finlay equipment.
At any given time you can see the exact location and status of your crushers and screeners.
But even better, this information also shows you precisely what areas you can improve in order to remotely optimise your profitability without needing to be standing beside your machine.
Activating T-Link on your Terex Finlay machine couldn't be simpler. Simply send an email to: finlay.tlink@terex.com and quote the serial number of your machine and we will activate the account for your machine and set you up to receive your 'Weekly Digest' report.
T-Link has been fitted to all Terex Finlay crushers* since 1st January 2016 and screeners* from 1st January 2017 (*machines fitted with electronic engine).
