FEED CONVEYOR / HOPPER:

• Width: 1200 mm (48")
• Drum centres: : 4.11m (13’ 6’’)
• Variable speed
• Target area: 4.75m x 2m (15’ 7’’ x 6’ 7’’)
• Hopper capacity: 7m³  (9.15 Cu. Yd.)

TRACKS

• Shoe Width: 400mm (1' 4‘’)
• Sprocket Centers: 4300mm (14' 1'')
• Speed: 1.1km/h (0.68mph)

POWERUNIT

• Fully protected power unit with easy access for service and maintenance
• Stage 3A: CAT C4.4 83kW (111hp)
• Tier 4/Stage VI: CAT C4.4 82kW (110hp)
• Stage V: CAT C3.6**
• Fuel tank volume: 325L (85 US GAL)

**Contact factory for availability

CONVEYOR LENGTH:

• 22.5m (73'10")

CONVEYOR BELT WIDTH:

• 1200mm (48'')

STOCKPILE CAPACITY

• Discharge Height @ 24°: 1735m3 (2270 Cu.Yd)

DRIVE DRUM DIAMETER:

• 345mm
