J-960
The Finlay® J-960 is the most compact tracked jaw crusher in the Terex® Finlay range. This aggressive and versatile crusher is ideal for small scale on-site crushing of aggregates and construction demolition wa...
J-1175
Jaw Crusher
The Finlay® J-1175 Tracked Jaw Crusher is a high performance and aggressive mobile crusher. Incorporating a Terex® Jaques JW42 jaw crusher and a heavy duty vibrating grizzly feeder, the Finlay® J-1175 gives optimum production in a range of applications.
Its compact size, quick set up times, ease of transport and simple maintenance make the Finlay® J-1175 Tracked Jaw Crusher ideal for quarrying, mining, demolition and recycling applications.
Key Features:
- The robust high performance hydrostatic driven single toggle jaw chamber provides high capacity with large reduction ratio’s.
- Automatic variable speed VGF ensures continuous choke feeding of the crushing chamber for optimal productivity.
- High powered hydrostatic drive ensures precise chamber controls and reverse functionality for clearing blockages and assisting in demolition and recycling applications.
- Fully hydraulic closed side setting minimises downtime and offers quick adjustment.
Downloads
Hopper / Feeder
By-pass conveyor (optional)
Jaw Chamber
Magnet seperator
Main Conveyor
T-Link Telematics
Video Gallery
Terex Finlay J-1175 jaw crusher
.tmb-768v.jpg?Culture=en&sfvrsn=92cdff79_1)
Terex Finlay J-1175 jaw crusher and C-1545 cone crusher
Terex Finlay J-1175 jaw crusher and C-1540 cone crusher
Terex Finlay J-1175 jaw crusher and C-1540 cone crusher (Quarry)
Terex Finlay J-1175 jaw crusher (Quarry)
Image Gallery
| Specification | Value |
|---|---|
| Net Engine Power | Tier 3 - CAT 350hp | Tier 4 Final / Stage V - Scania 345hp / Tier 3 - CAT 261kW | Tier 4 Final / Stage V - Scania 257kW |
| Inlet Opening | 42" x 30" / 1070mm x 760mm |
| Operating Weight | 113,096lbs / 51,300kg |
| Transport Dimensions | Height 11' 6'' | Width 9' 6'' | Length 47' 8'' / Height 3.5m | Width 2.9m | Length 14.5m |
| Working Dimensions | Height 12' 1'' | Width 20' 4'' | Length 51' 8'' / Height 3.9m | Width 20.4m | Length 15.7m |
REMOTE PLANT MAXIMISATION.
That's what Terex Finlays’ T-Link telematics system is all about.
T-Link telematics system is the optimum tool to connect you remotely to your Terex Finlay equipment.
At any given time you can see the exact location and status of your crushers and screeners.
But even better, this information also shows you precisely what areas you can improve in order to remotely optimise your profitability without needing to be standing beside your machine.
Activating T-Link on your Terex Finlay machine couldn't be simpler. Simply send an email to: finlay.tlink@terex.com and quote the serial number of your machine and we will activate the account for your machine and set you up to receive your 'Weekly Digest' report.
T-Link has been fitted to all Terex Finlay crushers* since 1st January 2016 and screeners* from 1st January 2017 (*machines fitted with electronic engine).
