TR-75 RADIAL CONVEYOR
The Terex® Finlay TR-75 Radial Stockpiling Conveyor is the ideal solution for stockpiling material after mobile crushing and screening plants to build a desegregated stockpile and ensure a consistent quality product.
It can also be integrated seamlessly into stationary plants. The mobility and flexibility of the TR-75 radial conveyors reduces / eliminates the use of a wheel loader on site and the inbuilt strength of the machine means it can be utilized in a wide range of applications from heavy duty primary jaw crushing to light duty screening applications.
With a maximum discharge height of 10.9m (34’ 9”) when operated in conical mode the machine will stockpile 3820 tonne of material. When configured to operate at 125° Kidney Bean mode the machine will stockpile 16064 tonne (17,707 US Tonnes) of material.
Key Advantages of Radial Conveyors
Radial conveyors aid production of high quality uniformed aggregate that are vital in the production of many materials such as concrete and asphalt. They help reduce:
- DEGRADATION
- SEGRAGATION
- CONTAMINATION
Conveyors operate at full work rate every hour of operation. This means time is spent doing what makes you money – loading your crusher.
- INCREASED PRODUCTIVITY
- REDUCED COST PER TONNE
When programmed to operate in kidney bean mode your primary crushing and screening plant can operate for days stockpiling without the need for intervention of a wheeled loader.
|
Deployment of radial conveyor reduces on site:
|
Adding radial stacker conveyors to stockpile material minimises operating costs.
- REDUCED MAINTENANCE COSTS
- REDUCED FUEL CONSUMPTION
Studies have shown that wheel loader maintenance can cost 95% more than conveyors annually. Along with this, fuel consumption can also be reduced compared to using wheel loaders. The Finlay TR-75 consumes on average 5.6 litres of fuel per hour.
Other Radial Conveyors available
RT-140 TELESCOPIC CONVEYOR
The Terex® Finlay RT-140 telescopic conveyor is essential for producers who want to produce a consistent quality product and reduce segregation, degradation, compaction and contamination of material in the stockpile.
The machine has eight automated stockpile modes available and the telescoping movement of the conveyor enables 30% more stockpiling capacity when compared against a standard radial stacker of the same length.
With a maximum discharge height of 14.4m (47’ 2’’) and configured to operate at 270° of radial movement the machine can stockpile an impressive 90,000 tonnes (99,200 US tonnes) of the material without intervention or the use of secondary equipment.
The RT-140 excels in sites with a limited footprint and can load or unload by truck, rail or barge.
WR-80 WHEELED RADIAL CONVEYOR
The Terex® Finlay WR-80 Wheeled Radial Stockpiling Conveyor is the ideal solution for stockpiling material after mobile crushing and screening plants to build a stockpile and ensure a consistent quality product. It can also be integrated seamlessly into stationary plants.
Available in either Pit or Road towable variants, the WR-80 is a simple but efficient radial conveyor. The machine is powered via hydraulic drive plug-in as standard enabling it to be powered by secondary equipment on site. The machine can also be configured with either electric or diesel hydraulic drive systems.
With a maximum discharge height of 9.95m (32’ 7”) when operated in conical mode the machine will stockpile 2313 tonnes (2544 US Tph) of material. When configured to operate at 270° Kidney Bean mode the machine will stockpile tonne 20144 tonnes (22158 US Tonnes) of material.
Applications
Quarry & Mining
Construction & Demolition
Recycling
